Isolation UPS (three - phase..)
※ A low frequency inductive isolation transformer is used to provide voltage regulation, noise and harmonic filtering, spike suppression and galvanic isolation.
※ LCD Chinese digital touch direct control operation interface, with password security boot and maintenance password protection functions
※ Made in Taiwan, safe and reliable.
※ Digital power design, small size, light weight, space saving, motorized mobile positioning of industrial-grade jack wheels.
※ Military protection grade, internal important digital parts are controlled by acid-proof, alkali- proof and waterproof ceramic circuit package for three-proof protection.
※ Multiple sets of different AC voltage output power supplies can be selected, which is suitable for applications with multiple loads.
※ Optional EPO emergency stop button ( with an anti- mistouch protective cover) can quickly stop the power output in an emergency.
※ Equipped with dry contact signal interlock function and standard RS-232 (optional SNMP RJ45 interface).
※ Abnormal fault status record, and can record 1000 groups of power operation and abnormal information to facilitate problem inquiry and analysis.
※ The whole machine adopts industrial and modular replacement design for quick and safe replacement and maintenance.
※ Industrial-grade mechanism design spare parts, double convection and diversion high-efficiency heat dissipation system, the working temperature can reach -40 ℃ ~ 55 ℃ .
※ Inrush current design is suitable for inductive loads such as motors and motors, and corresponding protection devices are made for their back electromotive force.
